  Overview


Below are the key specifications for the Jietu Shanhai L7, a mid-size plug-in hybrid SUV with various configurations:

Dimensions:

Length: 4,749 mm
Width: 1,900 mm
Height: 1,720 mm
Wheelbase: 2,745 mm
Powertrain:

Engine: 1.5L turbocharged inline-4, max output of 115 kW (156 hp), max torque of 220 Nm.
Electric Motor: Front-mounted single motor with max output of 199 kW (271 hp), max torque of 395 Nm.
Transmission: Dedicated hybrid transmission (DHT).
Performance:

Top Speed: 180 km/h.
Fuel Consumption (WLTC hybrid mode): 1.38 L/100 km.
Fuel Consumption in Depleted Battery Mode: 5.2 L/100 km.
Range & Efficiency:

Pure Electric Range:
120 km (CLTC cycle).
85 km (WLTC cycle).
Total Range: Up to 1,300 km.
Battery & Charging:

Battery Capacity: 19.43 kWh.
Fast Charging Time: 30%-80% charge in about 0.3 hours.
Slow Charging Time: Approximately 3 hours.
Other Specifications:

Fuel Tank Capacity: 60 liters.
Seating Layout: Available in 5-seat and 7-seat configurations.
